Perkins Generator Set

Powered by UK Perkins diesel engine, the Perkins generator set (9~2000kVA) is equipped with some famous brushless excitation alternators of Marathon and Stamford, and control panels of DeepSea UK.

Perkins Generator Set (9~2000kVA)

With automatic protective device, diesel generator set can automatically control and regulate the water temperature, oil temperature, oil pressure, and speed. It has many advantages such as automatic speed regulation, automatic voltage regulation, good dynamic performance, stable fluctuation of voltage, high efficiency, high reliability, long service life, and more. These generator sets can be combined as a power station group with automatic start system according to customer's requirements.

Perkins is one of the world's leading diesel engine manufacturers since 1932, with sales volume totaling nearly 400,000 units per annum. The engine series of 400, 1100, 1300, 2000 and 4000 feature full specification, reasonable structure, reliable performance, easy maintenance and low exhaust. As a result, they capture a large Chinese market. With high reliability and great durability, Perkins engines are highly sought after by major original equipment manufacturers in the industries of auto maker, construction, and more.

Bottom
50Hz Power Range (9 - 2250kVA) Powered by Perkins
Compact, Clean, Efficient
View Full Table
Model Prime Power Standby Power Engine Cylinders Displacement (L) Fuel Consumption(L/h) Lube Capacity(L) Open Version Soundproofed Version
kVA kW kVA kW L*W*H(mm) Weight (kg) L*W*H(mm) Weight (kg)
RPM7 9 7 10 8 403A-11G1 3L 1.1 < 2.6 4.9 1500*650*1225 425 2200*1030*1300 895
RPM7-1 9 7 10 8 403D-11G 3L 1.1 < 2.6 4.9 1500*650*1225 425 2200*1030*1300 895
RPM10 13 10 14 11 403D-15G 3L 1.5 < 3.6 6 1500*650*1225 495 2200*1030*1300 955
RPM10-1 13 10 14 11 403A-15G1 3L 1.5 < 3.5 6 1500*650*1225 495 2200*1030*1300 955
RPM16 20 16 23 18 404D-22G 4L 2.2 < 5.3 10.6 1500*650*1225 600 2200*1030*1300 1050
RPM16-1 20 16 23 18 404A-22G1 4L 2.2 < 5.3 10.6 1500*650*1225 600 2200*1030*1300 1050
RPM20 25 20 28 22 404D-22TG 4L 2.2 < 6.7 10.6 1500*650*1225 650 2200*1030*1300 1080
RPM24 30 24 33 26 1103A-33G 3L 3.3 < 7.0 7.9 1650*750*1280 780 2300*1130*1375 1270
RPM36 45 36 50 40 1103A-33TG1 3L 3.3 < 10.6 7.9 1650*750*1280 887 2300*1130*1375 1407
RPM48 60 48 65 52 1103A-33TG2 3L 3.3 < 13.8 7.9 1650*750*1280 908 2300*1130*1375 1434
RPM52 65 52 73 58 1104A-44TG1 4L 4.4 < 14.8 8 1750*850*1300 925 2300*1130*1375 1550
RPM64 80 64 88 70 1104A-44TG2 4L 4.4 < 18.4 8 1750*850*1300 1035 2300*1130*1375 1640
RPM73 91 73 100 80 1104C-44TAG2 4L 4.4 < 20.5 8 2240*850*1320 1175 2700*1130*1600 1735
RPM80 100 80 110 88 1104C-44TAG2 4L 4.4 < 24 8 2240*850*1320 1190 2700*1130*1600 1750
RPM109 136 109 150 120 1106A-70TG1 6L 7 < 30 16.5 2900*900*1530 1750 3600*1300*1900 2800
RPM116 145 116 160 128 1106D-E70TAG2 6L 7 < 39.7 16.5 2900*900*1530 1760 3600*1300*1900 2810
RPM120 150 120 165 132 1106A-70TAG2 6L 7 < 33.4 16.5 2900*900*1530 1765 3600*1300*1900 2815
RPM128 160 128 175 140 1106D-E70TAG3 6L 7 < 42.3 16.5 2900*900*1530 1770 3600*1300*1900 2820
RPM144 180 144 200 160 1106A-70TAG3 6L 7 < 41.6 16.5 2900*900*1530 1796 3600*1300*1900 2850
RPM150 188 150 205 164 1106D-E70TAG4 6L 7 < 48.3 16.5 2900*900*1530 1830 3600*1300*1900 2890
RPM160 200 160 220 176 1106A-70TAG4 6L 7 < 45.8 16.5 2900*900*1530 1840 3600*1300*1900 2900
RPM160-1 200 160 220 176 1506A-E88TAG1 6L 8.8 < 44.6 41 3000*1200*1830 2760 4100*1450*2040 4200
RPM184 230 184 250 200 1506A-E88TAG2 6L 8.8 < 48.6 41 3000*1200*1830 2770 4100*1450*2040 4210
RPM200 250 200 275 220 1506A-E88TAG3 6L 8.8 < 50 41 3000*1200*1830 2780 4100*1450*2040 4220
RPM220 275 220 300 240 1506A-E88TAG4 6L 8.8 < 60.2 41 3000*1200*1830 2860 4100*1450*2040 4300
RPM240 300 240 330 264 1506A-E88TAG5 6L 8.8 < 64.9 41 3000*1200*1830 2870 4100*1450*2040 4320
RPM280 350 280 400 320 2206C-E13TAG2 6L 13 < 70 40 3200*1210*1980 2930 4500*1580*2200 4700
RPM320 400 320 450 360 2206C-E13TAG3 6L 13 < 82.7 40 3200*1210*1980 3070 4500*1580*2200 4800
RPM360 450 360 500 400 2506C-E15TAG1 6L 15 < 95.6 62 3500*1540*1850 3400 4700*1580*2200 5040
RPM400 500 400 550 440 2506C-E15TAG2 6L 15 < 106 62 3500*1540*1850 3550 4700*1580*2200 5170
RPM480 600 480 660 528 2806C-E18TAG1A 6L 18 < 126.6 62 3500*1540*2050 3800 4700*1980*2200 5990
RPM520 650 520 700 560 2806A-E18TAG2 6L 18 < 129.3 62 3500*1540*2050 3925 4700*1980*2200 6040
RPM600 750 600 825 660 4006-23TAG2A 6L 23 < 152.3 113.4 4350*1750*2270 5500 6058*2438*2591 10350
RPM640 800 640 880 704 4006-23TAG3A 6L 23 < 171.8 113.4 4350*1750*2270 5570 6058*2438*2591 10420
RPM720 900 720 1000 800 4008TAG1A 8L 30.6 < 188 153 4700*2070*2414 6650 6058*2438*2591 11660
RPM800 1000 800 1100 880 4008TAG2A 8L 30.6 < 215.2 153 4700*2070*2414 6800 6058*2438*2591 12050
RPM1000 1250 1000 1375 1100 4012-46TWG2A 12V 46 < 258.1 177 4800*2200*2477 9950 12192*2438*2896 17950
RPM1080 1350 1080 1500 1200 4012-46TWG3A 12V 46 < 279.1 177 4900*2200*2477 10200 12192*2438*2896 18200
RPM1200 1500 1200 1650 1320 4012-46TAG2A 12V 46 < 299 177 4900*2200*2477 10430 12192*2438*2896 18430
RPM1368 1710 1368 1875 1500 4012-46TAG3A 12V 46 < 367.3 177 5100*2200*2477 11200 12192*2438*2896 19200
RPM1460 1825 1460 2000 1600 4016TAG1A 16V 61 < 381.3 237 6100*2740*3120 13780 12192*2438*2896 21780
RPM1640 2050 1640 2250 1800 4016TAG2A 16V 61 < 434 237 6100*2740*3120 13875 12192*2438*2896 21875
RPM1600 2000 1600 2250 1800 4016-61TRG2 16V 61 < 422 237 6100*2740*3120 13900 12192*2438*2896 21900
RPM1800 2250 1800 2500 2000 4016-61TRG3 16V 61 < 467.6 237 6100*2740*3120 14900 12192*2438*2896 22900

60Hz Power Range (11 - 1713kVA) Powered by Perkins
Compact, Clean, Efficient
View Full Table
Model Prime Power Standby Power Engine Cylinders Displacement (L) Fuel Consumption(L/h) Lube Capacity(L) Open Version Soundproofed Version
kVA kW kVA kW L*W*H(mm) Weight (kg) L*W*H(mm) Weight (kg)
RPM9 11 9 12 10 403D-11G 3L 1.1 < 2.8 4.9 1500*650*1225 435 2200*1030*1300 950
RPM12 15 12 17 14 403D-15G 3L 1.5 < 4.3 6 1500*650*1225 500 2200*1030*1300 1000
RPM19 24 19 26 21 404D-22G 4L 2.2 < 6.2 10.6 1500*650*1225 610 2200*1030*1300 1130
RPM25 31 25 35 28 404D-22TG 4L 2.2 < 8.3 10.6 1500*650*1225 645 2200*1030*1300 1150
RPM28 35 28 38 30 404D-22TAG 4L 2.2 < 8.7 10.6 1500*650*1225 665 2200*1030*1300 1180
RPM42 53 42 59 47 1103A-33TG1 3L 3.3 < 12.4 7.9 1650*750*1280 890 2300*1130*1375 1485
RPM50 63 50 70 56 1104D-44TG1 4L 4.4 < 16.3 8.4 2240*850*1320 925 2500*1130*1566 1590
RPM54 68 54 75 60 1103A-33TG2 3L 3.3 < 16.6 7.9 1650*750*1280 910 2300*1130*1375 1485
RPM58 73 58 80 64 1104D-E44TG1 4L 4.4 < 18.7 8.4 2240*850*1320 950 2700*1130*1600 1780
RPM62 77 62 85 68 1104A-44TG1 4L 4.4 < 17.8 8 1750*850*1300 790 2300*1130*1375 1550
RPM72 90 72 100 80 1104A-44TG2 4L 4.4 < 23 8 1750*850*1300 800 2300*1130*1375 1600
RPM72-1 90 72 100 80 1104D-E44TAG1 4L 4.4 < 23.7 8 2240*850*1320 1015 2700*1130*1600 1800
RPM90 112 90 125 100 1104C-44TAG2 4L 4.4 < 27 8 2240*850*1320 1175 2700*1130*1600 1800
RPM90-1 112 90 125 100 1104D-E44TAG2 4L 4.4 < 27.7 8 2240*850*1320 1250 2700*1130*1600 1800
RPM122 153 122 168 134 1106A-70TG1 6L 7 < 35.2 16.5 2900*900*1530 1700 3600*1300*1900 2820
RPM130 163 130 178 142 1106D-E70TAG2 6L 7 < 36.9 16.5 2900*900*1530 1700 3600*1300*1900 2820
RPM136 170 136 188 150 1106A-70TAG2 6L 7 < 38.2 16.5 2900*900*1530 1725 3600*1300*1900 2850
RPM140 175 140 195 156 1106D-E70TAG3 6L 7 < 39.8 16.5 2900*900*1530 1725 3600*1300*1900 2850
RPM160 200 160 220 176 1106A-70TAG3 6L 7 < 46.4 16.5 2900*900*1530 1850 3600*1300*1900 2920
RPM196 245 196 270 216 1506A-E88TAG1 6L 8.8 < 54.2 41 3000*1200*1830 2750 4100*1450*2040 4500
RPM230 288 230 315 252 1506A-E88TAG3 6L 8.8 < 63.1 41 3000*1200*1830 2750 4100*1450*2040 4500
RPM250 313 250 344 275 1506A-E88TAG4 6L 8.8 < 68.2 41 3000*1200*1830 2750 4100*1450*2040 4500
RPM273 341 273 375 300 1506A-E88TAG5 6L 8.8 < 77.1 41 3000*1200*1830 2800 4100*1450*2040 4600
RPM320 400 320 438 350 2206A-E13TAG2 6L 12.5 < 90.3 40 3200*1210*1980 2950 4500*1580*2200 4775
RPM320-1 400 320 438 350 2206D-E13TAG2 6L 12.5 < 90.3 40 3200*1210*1980 2950 4500*1580*2200 4775
RPM354 443 354 500 400 2206D-E13TAG3 6L 12.5 < 94 40 3200*1210*1980 2985 4500*1580*2200 4800
RPM400 500 400 550 440 2506D-E15TAG1 6L 15.2 < 97.8 62 3500*1540*1850 3375 4700*1580*2200 5090
RPM410 512 410 575 460 2506A-E15TAG3 6L 15.2 < 97 62 3500*1540*1850 3400 4700*1580*2200 5100
RPM455 569 455 625 500 2506A-E15TAG4 6L 15.2 < 113 62 3500*1540*1850 3550 4700*1580*2200 5215
RPM500 625 500 688 550 2806A-E18TAG1A 6L 18.1 < 121.6 62 3500*1540*2050 3680 4700*1980*2200 5910
RPM545 681 545 750 600 2806A-E18TAG3 6L 18.1 < 139.7 62 3500*1540*2050 3770 4700*1980*2200 5960
RPM600 750 600 825 660 4006-23TAG2A 6L 23 < 173.4 113.4 4350*1750*2270 5300 6058*2438*2591 10170
RPM675 844 675 938 750 4006-23TAG3A 6L 23 < 196.6 113.4 4350*1750*2270 5600 6058*2438*2591 10420
RPM707 884 707 975 780 4008TAG1 8L 30.6 < 210.5 166 4700*2070*2414 6460 6058*2438*2591 11520
RPM800 1000 800 1100 880 4008TAG2 8L 30.6 < 213 166 4700*2070*2414 6700 6058*2438*2591 11720
RPM1000 1250 1000 1375 1100 4012-46TWG2A 12V 46 < 261.8 177 4700*2200*2477 9750 12192*2438*2896 17800
RPM1094 1368 1094 1500 1200 4012-46TWG3A 12V 46 < 287.7 177 4800*2200*2477 10030 12192*2438*2896 18000
RPM1208 1510 1208 1655 1324 4012-46TAG2A 12V 46 < 313.9 177 4800*2200*2477 10100 12192*2438*2896 18100
RPM1370 1713 1370 1880 1504 4012-46TAG3A 12V 46 < 356 177 4900*2200*2477 10500 12192*2438*2896 18500

All ratings are for guidance only, please refer to the specific genset technical data sheet for final power ratings.
● All ratings data is based on operation under ISO 8528, ISO 3046, DIN6271 conditions using typical fan sizes and drive ratios.
● All ratings are based on the following reference conditions:
Ambient temperature: 27oC - Altitude above sea level: 150 meters - Relative humidity: 60%
● Prime Power = Power at available load in lieu of main power network. An overload of 10% permitted for one hour in every twelve hours of
operation.
● Standby Power = Power available at a variable load in the event of a main power network failure up to a maximum of 500 hours per year. No over
load is permitted.
● Rated power factor: 0.80.
● Also available in the following voltages: 1P 220V/230V/240V; 3P 380V/220V, 400V/230V, 415V/240V/, 440V/254V.

In addition to the Perkins generator set, we also provide Cummins generator sets, Caterpillar generator sets, Deutz generator sets, marine generators, and more. With reliable qulity and reasonable prices, our equipment is popular in both domestic and overseas markets. Moreover, located in Guangzhou city, China, our company has easy access to convenient air, sea, and land transportation, which helps to decrease shipping charges of our customers. For any information about our Perkins generator sets or other equipment, please feel free to contact us. We at Rise Power are ready to serve you.
