Weifang Generator Set

Weifang Generator Set (13~188kVA)

Description of Weifang Gensets/ Generator Set
1. Generator set is powered by Weifang Engine;
2. The gensets adopt renowned brand engine (Deutz and Cummins etc.), advanced generator and completely sealed automatic voltage regulator (AVR);
3. It is convenient to operate;
4. The generator set is excellent in performance and smooth in running;
5. Technical parameter of low-noise diesel generator sets: rated voltage 400(380)V (depend on client's choice); rated speed :1500r/min or1800r/min; rated frequency: 50Hz/60Hz; rated power factor: 0.8(lagging);

Major Parts of Diesel Generator Sets: diesel engine, alternator, control panel, base frame, etc.

Starting Method of Weifang Gensets/ Generator Sets
1. Automatic starting wholly: when power supply has been stopped, the generator sets can automatically start three times in 3-28 seconds (adjustable);
2. 12 seconds are needed for it to accept load when electric supply is resumed, and the generator will continue work in 23-230 seconds, then shut down automatically.

Control System for the Gensets
1. Apparatus: voltage meter, frequency meter, amperage meter, voltmeter of battery, meter of water temp., oil meter.
2. Control section: starting handler, key type switch, inductive type self-protection switch, and indicator.
3. Voltage: 400/230v
4. Rotation speed: 1500/1800 rpm
5. Cooling method: closed circulation cooling
6. Frequency: 50/60Hz
7. Power factor: 0.8(lagging)
8. Triple harmonic STC series or brushless TFW2 series or compound excitation TFX series of alternator.

Main Specifications of Weifang Generator Set

50/60Hz,  230V/400V,  13kVA - 188kVA, Soundproof Canopy
Generator Set  Model Engine    Model Alternator Model Frequency    (Hz) Prime Power Standby Power  Open Type Size (mm) Quantity for 20' Container Quantity for 40' Container
kW kVA kW kVA
RWM10 1100S TFX-10 50 10 13 11 14 1320x650x860 24 48
RWM12 1110s TFX-120 50 12 15 13 17 1320x650x860 24 48
RWM15 1125S TFX-15 50 15 20 17 21 1780x750x1000 14 28
RWM20 1125 TFX-20 50 20 25 22 28 1780x750x1000 14 28
RWM24 4100D TFX-24 50 24 30 26 33 1780x750x1000 14 28
RWM30 4100D TFX-30 50 30 38 33 41 1780x750x1000 14 28
RWM40 4100ZD TFX-40 50 40 50 44 55 1780x750x1000 14 28
RWM50 4105ZD TFX-50 50 50 63 55 69 1780x750x1000 14 28
RWM75 6105ZD TFX-75 50 75 94 83 103 2600x800x1500 4 8
RWM100 6105AZLD TFX-100 50 100 125 110 138 2600x800x1500 4 8
RWM120 6105AZLD TFX-120 50 120 150 132 165 2600x800x1500 4 8
RWM150 G128ZD TFX-150 50 150 188 165 206 2600x800x1500 4 8
