You are here : RISE Power Diesel Generator

China Diesel Generator, Power Generator, SDEC Generator Set

Home SDEC Gensets SDEC Generator Set (68~875kVA)

SDEC Generator Set

Bottom

Description:
SDEC generator set is a fully integrated power system powered by SDEC diesel engine, the engine, after being improved under the basis of SDEC diesel engine, has been greatly improved in quality, reliability, economical efficiency, vibration noise and shape. Most spare parts of this engine can be applied for the original models, which is the perfect engine for generator set made by following SATC MOTOR manufacturing standards
SDEC generator set adopts Deep Sea control system, which has a backlit LCD display to display clearly operation of generator set under any cases, it is also available in various features covering multi-language option, remote monitoring, frequency, voltage, current, oil pressure, water temperature and oil level monitoring as well as various alarms and automatic shutdown protection functions. The intelligent SDEC generator set has attenuated enclosure, paralleling system, ATS cabinet, and is available in GSM super remote monitoring and GPS positioning.
SDEC generator set has a whole set of maintenance-free battery starting system, in which the generator set can be started by injecting motor oil and coolant into the machine and switching on the positive and negative power supply, making it more convenient to use the machine. Due to 600,000 market supply and good after-sales services, the users can be free from worries of components supply and maintenance services.

Shanghai Diesel Engine Co.,Ltd, formally called as Shanghai Diesel Engine Factory, is established in 1947, now becomes a part of SAIC Motor, and it is a large state-owned high-tech enterprise specializing in developing and manufacturing of engine, engine parts and generator set. The company has a state-level technical center, a postdoctoral working station, world-level automatic production lines and a quality assurance system that meets passage cars standards.

In its nearly 70 years’ development, SDEC has exported its products all over the world. SDEC now has seven series of high quality diesel and natural gas engines, which cover R, H, D, C, E, G and W series. The power of these engine series are available in 50-1600kw, mainly applied for trucks, buses, construction machinery, generator sets, marine solutions and agricultural equipment. SDEC keeps on making service accessible to customers and has built a country-wide sales and service support system, which includes 19 central offices, 7 regional parts distribution centers, more than 300 core service stations and over 1000 service dealers.

Specification of SDEC generator set

Model Prime Power Standby Power Engine Cylinders Displacement (L) Fuel Consumption(L/h) Oil Consumption(g/kWh) Oil Capacity(L) Coolant Capacity (L) Dimension
kVA kW kVA kW L*W*H(mm) Weight(kg)
RSM55 68 55 75 60 SC4H95D2 4L 4.3 < 14.8 ≦0.3 15 6.8 1910*893*1170 940
RSM68 85 68 94 75 SC4H115D2 4L 4.3 < 18.7 ≦0.3 15 6.8 1950*893*1170 970
RSM80 100 80 110 88 SC4H160D2 4L 4.3 < 20.7 ≦0.3 15 6.8 2060*933*1185 1020
RSM95 118 95 130 104 SC4H160D2 4L 4.3 < 25.2 ≦0.3 15 6.8 2060*933*1185 1050
RSM105 131 105 144 115 SC4H180D2 4L 4.3 < 28.8 ≦0.3 15 6.8 2100*933*1185 1080
RSM128 160 128 176 141 SC8D220D2 6L 8.27 < 35.0 ≦0.3 22 8.2 2415*980*1500 1470
RSM140 175 140 193 154 SC7H230D2 6L 6.5 < 36.9 ≦0.3 20 9.6 2400*940*1376 1250
RSM150 188 150 206 165 SC7H250D2 6L 6.5 < 40.3 ≦0.3 20 9.6 2446*940*1376 1330
RSM160 200 160 220 176 SC8D280D2 6L 8.27 < 44.4 ≦0.3 22 8.2 2515*980*1500 1520
RSM180 225 180 248 198 SC9D310D2 6L 8.82 < 48.2 ≦0.3 22 8.2 2515*980*1500 1540
RSM200 250 200 275 220 SC9D340D2 6L 8.82 < 52.5 ≦0.3 22 12 2706*1040*1486 1750
RSM210 262 210 288 231 SC13G355D2 6L 12.88 < 54.9 ≦0.4 33 25.5 3156*1230*1674 2750
RSM250 312 250 343 275 SC13G420D2 6L 12.88 < 67.2 ≦0.4 33 25.5 3156*1230*1674 2850
RSM280 350 280 375 300 SC12E460D2 6L 11.8 < 73.6 ≦0.4 37 25.5 3175*1100*1595 2900
RSM300 375 300 413 330 SC15G500D2 6L 14.16 < 81.3 ≦0.4 33 25.5 3156*1230*1674 2970
RSM360 450 360 500 400 SC25G610D2 12L 25.8 < 97.2 ≦0.4 65 151 3533*1400*1992 4100
RSM410 512 410 562 450 SC25G690D2 12L 25.8 < 110.1 ≦0.4 65 151 3548*1400*1992 4300
RSM450 563 450 625 500 SC27G755D2 12L 25.8 < 121.2 ≦0.4 65 151 3548*1400*1992 4410
RSM550 688 550 750 600 SC27G830D2 12L 25.8 < 144.4 ≦0.4 65 151 3548*1400*1992 4450
RSM600 750 600 825 660 SC33W990D2 6L 32.8 < 158.4 ≦0.6 75 56 4362*1570*2135 7070
RSM700 875 700 962 770 SC33W1150D2 6L 32.8 < 195.4 ≦0.6 75 56 4433*1775*2378 8000
